Filling and capping is suitable for filling cans - jars etc... with liquid, dense and semi-dense products and for capping with Twist Off capsule, aluminum, threaded or pre-threaded caps

It is made up of:

- Patented volumetric dosing unit

- Capping unit

- Covered with vacuum bell (in option)

- Labeling unit (optional)

→Suitable for liquid and dense products (honey, jams, mayonnaise, sauces, melted cheeses, creams, etc.),

Piston made entirely of AISI304 stainless steel with Teflon seal, suitable for food, heat sterilizable, adjustable from 30 to 680 cc (optional from 40 to 1300 cc) with micrometric screw

Pneumatically controlled three-way valve with double buffer.

Power: compressed air

Format capacity: dose from 1 to 5,200 ml

It can be supplied with a stainless steel 'clamp' fitting and rubber holder to insert a flexible product feed tube or with a hopper completely made of stainless steel, with mirror polished inside, available with a capacity of 6-15-30-30 litres.

Format capacity: dose from 1 to 5,200 ml

Power: compressed air

Materials in contact with the product: AISI 316 stainless steel - PTFE

This specific machine model has been designed, built and certified for capping with Twist-Off capsules, aluminum caps (oil, vinegar, wine...) and PE (cosmetics).

Machine suitable for professional use, built in stainless steel and plastic parts suitable for use in the food industry.

The operator manually loads the container to be covered on the plate, the work cycle is activated by simultaneously pressing the two start buttons on the sides of the machine. The machine stops automatically at the end of the capping cycle, until the next start-up.

A pneumatic piston presser locks the canister in its proper seat.

The adjustment of the closing head, to adapt the machine to different jars, is extremely simple and fast.

The capper is supplied complete with pneumatic closing head complete with universal closing cone to treat different sizes of capsules without any change of accessory.

AISI 304 stainless steel machine base

Production: 400 - 700 b/h (depending on the type of product and packaging)

Pneumatic Supply: 6 Bar

Alternatively, it can be configured with a vacuum chamber or a labeller.
